HBGQ22F series metal button switch (with IP65/IK10 protection level)

Photos

Attributes

HBGQ22F series metal button switch (with IP65/IK10 protection level)

$9.43 / individual

Reference Price

1individual (Min. Order)

Ship From

Songjiang District, Shanghai

Shipping

To be negotiated with the supplier

Customization

For customization requests, please

Product Recommendations

Micro travel metal button HBGQ12mm metal electronic switch provides efficient and reliable products

Red wave button 16 19 22mm reset self-locking strip light equipment power button metal switch normally open and normally closed

Red wave button 16 19 22mm reset self-locking strip light equipment power button metal switch normally open and normally closed

16 19 22mm dual control double throw red wave waterproof metal button switch with light power self-locking self resetting 220V

16 19 22mm dual control double throw red wave waterproof metal button switch with light power self-locking self resetting 220V

Micro travel metal button 19mm button switch provides efficient and reliable products

Micro travel metal button HBGQ16mm metal electronic switch provides efficient and reliable products

Micro travel metal button HBGQ16mm metal electronic switch provides efficient and reliable products

Plastic button switch HBY5-KA series (plastic head) provides efficient and reliable products

Plastic button switch HBY5-KA series (plastic head) provides efficient and reliable products

Red Wave Y5 button switch self resetting flat button 22mm normally open and normally closed XB2be101 start stop control self-loc

Red Wave Y5 button switch self resetting flat button 22mm normally open and normally closed XB2be101 start stop control self-loc

Price Disclaimer

Brand

HBAN/Hongbo

Does it support customized processing

Yes

Installation size

10mm

Button head style

High head/flat head

Operation mode

Self resetting/self-locking

Operation stroke

About 2.5mm

Electrical life

Over 50000 times

Rated heating current

2A

Reset mode

Self resetting

Contact resistance

≤ 50m Ω

Head protection level

IP65 IK08

Working environment temperature

-25 ℃~+55 ℃ (no freezing) ℃

3C certificate number

2020970305001749

Warranty

5 years

Shell material

304 stainless steel

Switch rating

≤ 100mA

Switch combination

1NO 1NC

sellable

Beijing; Tianjin; Hebei Province; Shanxi; Inner Mongolia; Liaoning; Jilin; Heilongjiang Province; Shanghai; Jiangsu; Zhejiang; Anhui; Fujian; Jiangxi; Shandong; Henan; Hubei; Hunan; Guangdong; Guangxi; Hainan; Chongqing; Sichuan Guizhou; Yunnan; Xizang; Shaanxi Gansu; Qinghai; Ningxia; Xinjiang

Model

HBGQ10F-11
