Explosion proof pipeline heater, air electric heater, circulating heating, high-pressure nitrogen heating, liquid water heating

Photos

Attributes

Explosion proof pipeline heater, air electric heater, circulating heating, high-pressure nitrogen heating, liquid water heating

$285.71 ~ 314.29

Reference Price

1table (Min. Order)

WY-GD

20KW

$285.71

50KW

$285.71

Ship From

Yancheng City, Jiangsu Province

Shipping

To be negotiated with the supplier

Customization

For customization requests, please

Product Recommendations

View Details

Manufacturer of pipeline heater, compressed air, nitrogen heater, stainless steel explosion-proof fluid electric heater

$314.29

View Details

Non standard customized hydrogen pipeline heater, compressed air gas explosion-proof electric heater

$314.29

View Details

Thermal oil electric heating mold temperature machine, reaction kettle, mixing tank, matching electric heating oil furnace

$471.43

View Details

Thermal oil heater for explosion-proof reaction kettle, Thermal oil boiler, Hot press roller drying room with constant temperatu

$471.43

View Details

Wanyan Electric Thermal Heating Thermal Oil Furnace 300KW Thermal Oil Heater Drying Room Heating Special

$471.43

View Details

Stainless Steel Horizontal Pipeline Electric Heater Steam Overheating Constant Temperature Compressed Air High Temperature Gas H

$314.29

View Details

Manufacturer of pipeline heater, compressed air heating furnace, liquid fluid, heavy oil heating, sewage treatment heating equip

Does it support customized processing

yes

material

carbon steel, stainless steel

operating pressure

1.6MPa

forming cycle

working voltage

440V

nominal pressure

1PN

power

160KW

number of pipes

structural form

fully welded structure

diameter

100mm

type

thermal oil pipeline heater

continuous service life

8000h

applicable machinery

petroleum, chemical, food, machinery, etc.

shape

pipeline explosion-proof heater

temperature range

300 ℃

model

WY-GD-D 230809-02

application field

Heating equipment for ovens, boilers, chemical appliances, building materials, etc.

application range

Air liquid nitrogen electric heating

weight

190kg

application

Environmental engineering, high temperature testing, explosion-proof workshop, gas heating, liquid heating

electrical strength

2000V

customized processing

Yes

protection method

Over temperature alarm, over temperature power-off, leakage protection

certificate

ISO9001-2015, CCC

thermal efficiency

Over 95%

warranty period

1 year

structure

Fully welded structure

cold insulation resistance

≥ 50M Ω

design pressure

0-20mpa

heating element

Stainless steel flange heating tube

usage environment

Suitable for both indoor and outdoor use

brand

Wan Yan
